Hela Tiles
Color :
Hela Tile Manufacturer and Exporter
Product Specification: Hela Tiles (Complete Series)
| Specification | Hela | Hela Eave | S2 | Hela Gable | Hela-L | Hela Wall-eave | Valance |
|---|---|---|---|---|---|---|---|
| Length (mm) | 300 ± 3 | 235 ± 2 | 287 ± 3 | 300 ± 3 | 155 ± 1 | 380 ± 3 | 302 + 3 |
| Width (mm) | 200 ± 2 | 200 ± 2 | 215 ± 5 | 100 ± 1 | 120 ± 1 | 200 ± 2 | 152 + 2 |
| Cover Length (mm) | 130 ± 1 | N/A | 260 ± 2 | 130 ± 1 | N/A | 130 - 230 | N/A |
| Max. Unit Weight (kg) | 2.1 | 1.8 | 2.8 | 1.2 | 1.0 | 2.8 | 1.1 |
| Longitudinal Camber (mm) | -2 to +2 | -2 to +2 | N/A | -2 to +2 | -2 to +2 | -2 to +2 | N/A |
| Transverse Camber (mm) | -2 to +3 | -2 to +3 | N/A | -2 to +3 | -2 to +3 | -2 to +3 | N/A |
| Transverse Strength (N) | > 900 | N/A | N/A | > 900 | N/A | N/A | N/A |
| Water Absorption (%) | < 10 | < 10 | < 10 | < 10 | < 10 | < 10 | < 10 |
